Dräger Narkoseuhr – Mechanical Pulse and Respiration Clock, circa 1948–1952

Dräger Narkoseuhr – Mechanical Pulse and Respiration Clock, circa 1948–1952

€260,00 EUR
A distinctive instrument from the history of anesthesia, this mechanical Dräger Narkoseuhr combines a central clock with scales for determining pulse and respiratory rates. Its gray-green hammer-finish housing, polished metal bezel, and contrasting dial give it a striking medical-industrial appearance. The lower edge of the dial is marked DRÄGER NARKOSEUHR. German inscriptions refer to counting 15 heartbeats and 5 breaths, with corresponding scales indicating the rate per minute. HISTORICAL BACKGROUND According to information supplied by the seller, this example was made by Drägerwerk Lübeck, Germany, circa 1948–1952. The seller identifies this type as designed for mounting on mobile Dräger anesthesia machines, such as the Model F and the Romulus (1952). This dating and model application have not been independently confirmed. The rear bears the marking AH. The serial number is 1306, according to the seller. An appealing collectible for enthusiasts of historical clocks, medical instruments, and Dräger’s technical heritage. DETAILS AND CONDITION Brand: Drägerwerk Lübeck, Germany, according to seller information. Type: Mechanical Narkoseuhr / Pulsuhr with pulse and respiration scales. Estimated date: Circa 1948–1952, according to seller information. Markings: DRÄGER NARKOSEUHR and AH; serial number 1306 according to the seller. Dimensions: 12 × 10 × 7 cm. Weight: 614 g. Tested by the seller; accuracy and calibration have not been established. Pre-owned vintage condition with visible signs of use and age on the housing and metal components. Please examine the photographs for condition details. Offered as a historical collectible, not as an instrument for medical measurements. Only the pictured Dräger Narkoseuhr is included; other objects visible in the background are not part of the sale. Only one example of this product is available. Tracked shipping is charged separately.
